TH30S-B Temperature & Humidity PROBE

• Two options of plug, Micro USB and Audio plug
• Wide monitoring range: -40 to 80 ℃/ 0 to 100% RH
• Accurate readings, remotely accessbile
• Rain / spray / dust resistant
• Pairs WS1 Pro and GS1 device

The external air temperature and humidity probe TH30S-B combines temperature and humidity sensors into one probe; can monitor two metrics at a time.

Due to its moderately waterproof and dustproof characteristics, you can deploy this probe in dusty or highly humid environments.

It has exquisite appearance and high measurement accuracy.

The probe comes with a Micro USB or a 3.5 mm audio plug; can be used with WS1 Pro, GS1 series, and SP1.

FEATURES:

• Temperature and humidity sensors combined into one probe, monitoring 2 metrics at the same time
• RS485 ModBus Protocol makes sure data transmission is accurate and stable
• Temperature measuring range: -40 °C to +80 °C (-40°F to +176°F); Measuring Humidity Range: 0
• to 100% RH
• Accuracy: ±0.3 °C, resolution 0.1 °C; ±2% RH, resolution 0.1% RH (in the condition of 25 °C, 60% RH)
• Working with WS1 Pro, GS1 series, and SP1
• IP42

NOTE:

- Only one TH30S-B probe can be connected to a UbiBot device at a time.

- TH30S-B should be connected to the lower USB port (USB2) on the WS1 Pro device.

- TH30S-B is disabled by default. Please enable it in "Settings" in the App or the Web Console after connecting the probe to the device. The GS1 device doesn't need this operation.

- This product is designed to work exclusively with UbiBot devices.

UbiBot ® offers a revolutionary way to monitor environmental conditions where they matter. The sensors synchronize data to UbiBot ® IoT Platform using WiFi, Cellular or Ethernet connection (depending on the specific model purchased). Users can then access data from anywhere via a smartphone or the Web console.

FEATURES:

• Data Management: Manage all your IoT data in one place; you could add as many devices as you want to one UbiBot account.
• Unlimited Storage: Unlimited cloud-based storage ensures you will never run out of space. This allows you to view all your historical data via UbiBot App or Web.
• Free App & Web Console: Using UbiBot App and Web Console is free. Powerful and thoughtful features provide you brilliant experience.
• Analysis and Visualization: Use powerful analysis and visualization tools to get the most out of your data; spot trends and direct comparisons.
• Real-Time Alerts: Fully customizable alert system will notify you via App notifications, emails, phone call/SMS, HTTP whenever any metric goes out of the range preset.
• Highly Secure Platform: UbiBot IoT platform is designed to keep all your data secure so you never have to worry about hackers or other security issues.
• Working with IFTTT, Alexa, Google Assistant, Google Sheet
• Compliant with FDA CFR21

DETAILS:

Real-time and history data

The UbiBot Platform is a cloud-based IoT platform where all measured data is uploaded and stored. UbiBot App and Web Console allow you to view current data as well as historical data in graphs. The adjustable Y-axis scale allows you to view any tiny fluctuations in the curve.

Customizable alerts and bulk operation

Setting and receiving alerts on your devices helps you to get notified of the conditions timely. When you have many devices to manage, it’s time-consuming to set each alert rule one by one. Therefore, we’ve developed a bulk operation module with which you can set the same rule for many devices at a time.

Free data export

On UbiBot Platform, you can download the history data in CSV or PDF format. The CSV file only contains raw data, while the PDF file is a summarized report with average, maximum and minimum value within the chosen period. The PDF file is much easier to read and archive.

Device sharing and bulk operation

For business users, centralized control over multiple devices is available, with no limit on the number of devices in one account. Also available are bulk operations that apply to sensor settings, alerts, and remote control routines. Devices can be shared with other people, which allows for distributed management by different colleagues.

Intelligent automation in UbiBot platform

UbiBot is committed to building intelligent industrial and home ecosystems. By integrating temperature and humidity sensors and the smart plug SP1 in one system, automated operation is achieved through data linkage. For example, fans can be switched on when the temperature rises to 30 °C.

Data forwarding

UbiBot is an open platform that provides cloud-based services while supporting customers to use their own storage servers. With the data forwarding service, you can forward the data collected by your device to your own private URL to protect privacy.

Location tracking and logging

UbiBot GS1-PL4G1RS is embedded with GNSS (Global navigation satellite system) for positioning. Through mobile data communication, real-time location information is transmitted to the platform and recorded. The UbiBot platform integrates this data, plots it into a trajectory map, and presents it.

Platform-based calibration

UbiBot platform supports data calibration both on the platform level as well as the device level. One-step calibration, instant display, no impact on historical data.

SIM card management

When using UbiBot Global SIM to transfer data, you can manage it by yourself. Unlike other SIM cards with a standard monthly fee and traffic amount, our SIM supports many types of plans. Choose the one that suits you now, and change to another next time. No arrearage and no extra charge.
