UbiBot LoRa Gateway GW1

$279.00 USD

Sale Sold out

Style GW1-24FETH Wi-Fi + RJ45 Ethernet GW1-24F4G Wi-Fi + 4G Cellular

Frequency Band US915 (W9） EU868 (W8） AU915 RU864 KR920 AS923 IN865

Description

Up to 1 km Range - Leverage LoRa’s superior signal penetration for reliable outdoor coverage without repeaters.
Ultra-Low Power Consumption – Designed for energy-efficient operation, extending battery life of connected sensors and reducing maintenance.
100-Node Scalability – Seamlessly manage and aggregate data from up to 100 UbiBot LoRa tags or sensors via a single gateway.
Flexible Multi-Network Connectivity – Connect to the UbiBot Cloud over Wi-Fi, 4G cellular, or RJ45 Ethernet for uninterrupted data flow.
Real-Time Status Dashboard – Intuitive LED indicators and cloud UI show network health, data transmission, and device status at a glance.
Rugged & Reliable – Operates from –20 °C to 60 °C with 10–90% RH tolerance (non-condensing), ideal for industrial, agricultural, and smart-building environments.
Cost-Effective Rollout – Minimize infrastructure expenses with LoRa’s long range and low deployment requirements—no extensive cabling needed.
Future-Ready Tag Ecosystem – Upcoming release of diverse LoRa tag types (temperature, humidity, door/window, vibration, and more) will enrich your monitoring solutions.

View full details

UbiBot IoT Platform

A Long-Range, Low-Power Wireless Communication

With LoRa technology, our gateway ensures extended wireless communication with wide signal coverage and strong penetration. Achieve reliable, long-range transmission of up to 1 km in ideal outdoor environments.

Multiple Nodes Connectivity

Supports seamless wireless communication with up to 100 UbiBot LoRa sensors, making your system a cutting-edge monitoring solution.

Unleash Maximum Efficiency with Ultra-Low Power

Our LoRa gateways and nodes are designed for high performance with low power consumption. Experience seamless connectivity with optimal frequency, wireless channels, and fast transmission speeds, all while conserving energy.

High Sensitivity

Strong Interference Resitance

Flexible Configuration

High Concurrency

Low Power Consumption

Bi-Directional Communication

Real-Time Status at a Glance

Seamlessly display the status of network connectivity, LoRa communication, and device performance. Stay effortlessly informed with clear, real-time indicators designed for instant visibility.

Unlock Cost-Effective, Long-Range Connectivity with LoRa Technology

Experience the benefits of low power consumption and extended range with LoRa wireless technology, significantly cutting deployment costs by eliminating the need for complex wiring. LoRa's robust signal penetrates obstacles, ensuring wide coverage, while a single gateway manages up to 100 devices simultaneously.

Range

Latency

Data
Throughput

Power
Consumption

Network
Requirements

Cost &
Deployment

Applications

LoRa

Long

Suitable for non-real-
time applications

Low (small data
packets)

Extremely low

Gateway required

Low cost,
large-scale use

Long-range, low power
consumption

WiFi

Medium

Low

High (large data
transfer)

High

Full network coverage

High cost, indoor
use

High bandwidth,
short-range

4G

Long (depends on
base stations)

Low

High (large data
transfer)

High

Full network coverage
(carrier-dependent)

High cost, data plan
required

High bandwidth,
outdoor applications

Bluetooth

Short

Low (simple tasks)

Low (small data
packets)

Low

Base station/phone
required

Low cost, small-scale
use

Short range, low power
consumption

Specifications

Model	GW1-24FETH	GW1-24F4G
Dimensions	190mm × 190mm × 40mm	190mm × 190mm × 40mm
Weight	295g±3	298g±3
Material	ABS + PC	ABS + PC
Power Supply	DC 12V / PoE	DC 12V / PoE
Internal Memory	300,000 sensing records	300,000 sensing records
Operating Environment	Temperature: -20°C ~ 60°C Humidity: 10% ~ 90% (non-condensing)	Temperature: -20°C ~ 60°C Humidity: 10% ~ 90% (non-condensing)
Certifications	CE, RoHS, FCC	CE, RoHS, FCC
Communications & Interfaces
LoRa Frequency Band	RU864 / IN865 / EU868 / US915 / AU915 / KR920 / AS923	RU864 / IN865 / EU868 / US915 / AU915 / KR920 / AS923
Network	WiFi 2.4GHz (channels 1 ~ 13) RJ45 Ethernet	WiFi 2.4GHz (channels 1 ~ 13) RJ45 Ethernet Mobile Network: 4G
Device Interfaces	Type-C / DC power input / RJ45 port	Type-C / DC power input / RJ45 port / SIM card slot
Sensors & Accessories
Accessories	PoE Splitter	PoE Splitter

Common Documents

GW1-User-Guide-English

UbiBot APP User Guide

UbiBot Platform User Guide

Temperature Calibration

Relevant Industrial Standards

Multiple Network Connection Methods

UbiBot Gateway GW1 can be connected to the UbiBot IoT big data platform through WiFi / 4G / RJ45 Ethernet cable, allowing full control and monitoring of connected sensors from multiple terminals like mobile / tablet and laptop.
